Specifications
| Measurement Lines: | Single-phase / two-wires |
| Measurement Items: | Voltage, Current, Active power, Apparent power, Reactive power, Power factor, Phase angle, Frequency, Current or Power integral |
| Measurement Ranges: | Voltage: 15.00 V to 600.0 V, 6 ranges Current: 500.0 mA to 20.00 A, 6 ranges, (direct input type) Shunt Input (for current): 50 mV or 100 mV, 2 ranges Power: 30 W to 300 kW, 48 ranges Frequency: 500 Hz or 50 kHz, 2 ranges |
| Integration Range: | 0 to ±999999 MWh, 0 to ±999999 MAh, 1 minute to 1000 hours integration time |
| Basic Accuracy: | ±0.25 % rdg. ±0.1 % f.s. (active power, at 45 to 66 Hz) |
| Frequency Characteristics: | DC, or 10 Hz to 20 kHz (±3 % f.s.) |
| Signal Output: | Analog level: 2 V DC /full scale range, 3 channel (active power, voltage, current) Waveform monitor: 2 V /full scale range, 2 channel (voltage, current) D/A output: (Apparent power, Reactive power, Power factor, Phase angle, Frequency, Current or Power integral) |
| Other Functions: | Display scaling, display averaging, PT or CT scaling |
| Sampling Rate: | 5 times/second |
| Power Supply: | 100 to 240 V AC, 50/60 Hz, 4 types (specify when ordering) |
| Dimensions: | 215 mm(8.46 in)W × 80 mm(3.15 in)H × 280 mm(11.02 in)D |
| Weight: | 3.3 kg (116.4 oz) |
| Accessories: | Power cord (1), Fuse (1) |
option; 9588 GPIB Interface
