제품명
High Voltage Power Supply
제조사
SRS
모델
PS325
가격
문의요
렌탈
문의요
첨부파일
상세내용
| Specifications | ||
| Model | Output Voltage (±) | Max. Current |
| PS325 | 0 to 1.25 kV | 10 mA |
| Voltage Output | ||
| Voltage set accuracy | 0.01 % + 0.05 % of full scale | |
| Voltage display accuracy | Vset accuracy ±1 V, typ. (±2 V, max.) | |
| Voltage resolution | 1 V (set and display) | |
| Voltage resettability | 1 V | |
| Voltage limit range | 0 to 100 % of full scale | |
| Voltage regulation | 0.001 % for ±10 % line change 0.04 % for 100 % load change Specifications apply for >0.5 % (full load) to >1 % (no load) of full scale voltage. | |
| Output ripple (Vrms) | ||
| 25 W models | 0.002 % of full scale | |
| 10 W models | 0.01 % of full scale | |
| Current limit range | 0 to 105 % of full scale | |
| Trip current | 10 µA (min.) | |
| Trip response time | <10 µs | |
| Current set accuracy | ||
| 25 W models | 0.01 % + 0.05 % of full scale | |
| 10 W models | 1 % + 0.05 % of full scale | |
| Current resolution | 10 µA (PS310 and PS325) 1 µA (all other models) | |
| Current display accuracy | ±10 µA (typ.), ±20 µA (max.) (PS310 and PS325) ±1 µA (typ.), ±2 µA (max.) (all other models) | |
| Stability | 0.01 % per hr., <0.03 % per 8 hrs. | |
| Temperature drift | 50 ppm/°C, 0 °C to 50 °C (typ.) | |
| Protection | Arc and short circuit protected. Programmable voltage limit, current limit and current trip | |
| Recovery time | 12 ms for 40 % step change in load current (typ.) | |
| Discharge time | <6 s (to <1 % of full-scale voltage with no load, typ.) | |
| Monitor Output | ||
| Output scale | 0 to +10 V for 0 to full-scale output regardless of polarity | |
| Current rating | 10 mA (max.) | |
| Output impedance | <1 Ω | |
| Accuracy | 0.2 % of full scale | |
| Update rate | 8 Hz | |
| External Voltage Set | ||
| Input scale | 0 to +10 Volts for 0 to full-scale output regardless of polarity | |
| Input impedance | 1 MΩ | |
| Accuracy | 0.2 % of full-scale | |
| Update rate | 16 Hz | |
| Output slew rate | <0.3 s for 0 to full-scale under full load | |
| Mechanical Specifications | ||
| HV connector | ||
| PS310/325/350 | Kings Type 1704-1 | |
| PS355/365 | Kings Type 1064-1 | |
| PS370/375 | Kings Type 1764-1 | |
| Mating connector | ||
| PS310/325/35 | Kings Type 1705-1 | |
| PS355/365 | Kings Type 1065-1 | |
| PS370/375 | Kings Type 1765-1 | |
| Dimensions | 8.1" × 3.5" × 16.0" (WHL) | |
| Weight | 8 lbs. | |
| Power | 50 W, 100/120/220/240 VAC, 50/60 | |
