제품명
Function Synthesizer Generator
제조사
NF
모델
WF1956
가격
문의요(재고유)
렌탈
문의요
첨부파일
상세내용
● Frequency setting range: 0.01μHz to 100MHz with frequency accuracy of ±5ppm for total bandwidth.
● Covers broadband of 0.01μHz to 100MHz by combining DDS method (0.01μHz to 15MHz) and PLL method (100kHz to 100MHz).
● HF mode (CH2): 100kHz to 100MHz with setting resolution of 0.1μHz.
● CH1 maximum output voltage: 20Vp-p/Open with maximum of 5 digits to be set and maximum offset voltage of ±10V/Open
● CH2 minimum amplitude range is 20 mV. Minute setting with amplitude setting resolution of 1μVp-p available.
● Output of five standard waveforms and arbitrary waveforms. The size of arbitrary waveform data can be changed among 8K/16K/32K words.
● CH2 square wave rise/fall time: 8 ns or less.
● Burst, trigger, gate, various sweep functions and modulation functions.
● Clock signal of 100MHz can be output from CH2 synchronized output. Output voltage:
－2V to +7V (Open), High/Low level can be set independently. Rise/Fall time is variable between 1.0V/ns to 2.8V/ns with setting resolution of 0.01V/ns
● Broadband and multi-function 2-channel output.
● GPIB interface is provided in the standard specification.
