100 MHz bandwidth

2 analog channels

Sample rates up to 1GS/s on all channels

1 Mega sample record length on all channels

5,000 wfm/s maximum waveform capture rate

Suite of advanced triggers Serial Bus Trigger and Decode

I2C, SPI, CAN, LIN, and RS-232/422/485/UART serial triggering,

   decode, and analysis options

▷ Ease of Use Features

Wave Inspector® Navigation and Search provides unprecedented efficiency in waveform analysis

FilterVuTM variable low-pass filter allows for removal of unwanted signal noise while still capturing high-frequency events

7in (180mm) bright, widescreen, TFT-LCD color display

USB 2.0 on front panel for quick and easy data storage

USB 2.0 device port on rear panel for direct PC control of oscilloscope using USBTMC or direct printing to any PictBridge® compatible printer

Plug 'n' Play PC connectivity and analysis software solutions

TekVPI® Probe Interface supports active, differential, and current probes for automatic scaling and units

Small footprint and light weight: only 5.3" (134 mm) deep and 7 lbs 14 oz (3.6 kg)

▷ Applications

Embedded design and debug

Power measurements

Automotive electronics

Education and training

Video design and debug
