Features & Benefits

• 60 MHz Bandwidths
• 1 GS/s Real Time
• 2 Channels
• 2.5K Record Length

• Color or Monochrome LCD Display
• Removable Data Storage using the Front-panel USB Port
• Seamless PC Connectivity through the USB Device Port, with OpenChoice® and NI SignalExpress® PC Software
• Advanced Triggers including Pulse Width Trigger and Line-selectable Video Trigger
• FFT Standard on All Models
• 12 Automatic Measurements
• Multiple-language User Interface and Context-sensitive Help
• Direct Print to all PictBridge®-compatible Printers through the USB Device Port
• Lifetime Warranty

Applications

• Design and Debug
• Education and Training
• Manufacturing Test and Quality Control
• Service and Repair
